BMS Protection Board Solution Solution for Battery Swap Cabinet Charger

BMS lithium battery protection board

Hippo BMS protection board is a protection board solution designed for 13~20 battery packs; it can be used for lithium batteries of different chemical properties, such as lithium ion, lithium polymer, lithium iron phosphate, etc. This protection board has a strong load capacity and the maximum continuous current can reach 100A. Various protection functions for charging and discharging/hardware overcurrent and short circuit protection functions/software and hardware two-level protection/3-way battery temperature detection, MOS temperature monitoring and passive protection/charging and discharging with the same port/4G module 4G, RS458 (support charging cabinet tower protocol)

Industry pain points

High-precision simulation and real-time challenges
BMS needs to process complex battery status information, such as voltage, current, temperature, etc., and the existing HIL (hardware-in-the-loop) test system has a persistent technical difficulty in simulating these parameters with higher accuracy and faster real-time response speed.
Insufficient safety verification
For BMS safety functions, such as overcharge protection, over-discharge protection, thermal management control, etc., it is sometimes still difficult to simulate the safety boundary conditions under real working conditions in a laboratory environment.

Product advantages

Excellent compatibility
Applicable to ternary lithium, lithium titanate, manganese oxide, iron phosphate, sodium ion batteries
Stable input and output
Charging and discharging with the same port/4G module 4G, RS458 (support charging cabinet tower protocol), continuous discharge and charging current 40~100A.
Personalized customization function
Supports personalized customization of host computer, APP, applet, display interface, supports customization of multiple communication protocols (CAN\485\TTL), to meet the various needs of different customers and different scenarios
Multiple protections are safer
Various protection functions for charging and discharging/hardware overcurrent and short circuit protection functions/software and hardware two-level protection/3-way battery cell temperature detection, MOS temperature monitoring and passive protection.
